Tecnologia
Panoramica tecnica
Telaio
Telaio:
Teammachine R 01 Premium Carbon with Aerocore Design | ICS Technology Stealth Cable Routing | Stealth Dropout Design | Flat Mount Disc | 12 x 142mm Thru-Axle
Forcella:
Teammachine R 01 Premium Carbon | ICS Technology Stealth Cable Routing | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Attacco Manubrio:
BMC ICS2 | Integrated Cockpit System Technology
Piega:
Easton EC70 SL Carbon or Easton EC90 SLX Carbon
Seat
Reggisella:
Teammachine R 01 Premium Carbon Seatpost | 10mm Offset
Sella:
Fizik Argo Vento R3 | 140mm
Gruppo
Guarnitura:
SHIMANO Ultegra FC-R8100
Corona:
52-36T
Potenziometro:
4iiii Precision 3+ Power Meter (Left Side)
Pacco pignoni:
SHIMANO Ultegra CS-R8100
Ingranaggi:
11-30T
Catena:
SHIMANO CN-M8100
Deragliatore:
SHIMANO Ultegra Di2 FD-R8150
Cambio:
SHIMANO Ultegra Di2 RD-R8150
Comandi:
SHIMANO Ultegra Di2 ST-R8170
Rapporti:
2 x 12
Movimento centrale:
PF86 Bottom Bracket
Freni
Leve Freno / Pinze:
SHIMANO Ultegra BR-R8170
Dischi freno:
SHIMANO RT-CL800
Diametro dischi:
160 / 160mm
Ruote
Cerchi:
CRD-501 Carbon | Tubeless Ready | 50mm
Mozzi:
CRD-501
Pneumatici:
Pirelli P Zero Race TLR | 26mm
Informazioni Tubeless:
Tubeless Ready Rims | Tubetype Tires
Accessori
Informazioni aggiuntive
Sezione max coperture:
30mm
Peso senza Pedali:
7.5 Kg
Classificazione ASTM:
Level 1
Limite di peso massimale :
110kg
Size | 47 | 51 | 54 | 56 | 58 | 61 |
---|---|---|---|---|---|---|
Rider Height | <166 | 166-174 | 172-180 | 178-186 | 184-192 | >190 |
Reach | 368 | 378 | 387 | 393 | 402 | 409 |
Stack | 504 | 528 | 548 | 563 | 582 | 608 |
Bar Reach | 76.9 | 76.9 | 76.9 | 76.9 | 76.9 | 76.9 |
Bar Width | 400 | 420 | 420 | 420 | 420 | 440 |
BB Drop | 69 | 69 | 69 | 69 | 69 | 69 |
Crank Length | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
Fork Length | 367 | 367 | 367 | 367 | 367 | 367 |
Fork Rake | 48 | 48 | 43 | 43 | 43 | 43 |
Front Center | 568 | 586 | 589 | 599 | 614 | 630 |
Head Tube | 108 | 133 | 149 | 165 | 185 | 211 |
Head Tube Angle | 71.5 | 71.5 | 72.3 | 72.3 | 72.3 | 72.3 |
Rear Center | 410 | 410 | 410 | 410 | 410 | 410 |
Seat Angle | 74 | 74 | 73.5 | 73.5 | 73 | 73 |
Seat Tube | 418 | 463 | 499 | 519 | 541 | 570 |
Seatpost Length | 335 | 335 | 385 | 385 | 405 | 405 |
Seatpost Offset | 10 | 10 | 10 | 10 | 10 | 10 |
Stem Angle | -6 | -6 | -6 | -6 | -6 | -6 |
Stem Length | 90 | 100 | 100 | 110 | 110 | 120 |
Top Tube | 522 | 532 | 552 | 562 | 582 | 598 |
Trail | 63 | 63 | 63 | 63 | 63 | 63 |
Wheelbase | 968 | 986 | 989 | 999 | 1015 | 1030 |
