Technische Übersicht
Rahmenset
Rahmen:
Teamelite 03 - Big Wheel Concept | Al-13 Premium Triple-butted - Hydroformed Aluminum
Cockpit
Lenker:
BMC MFB 03 | 720mm
Vorbau:
BMC MSM 03
Sattelstütze:
BMC MSP 03
Sattel:
VL-1831
Antrieb
Übersetzung:
2 x 10
Kurbel:
Shimano FC-M617 | 36-22T
Kassette:
Sunrace 11-36T
Kette:
KMC X-10
Umwerfer:
Shimano Deore
Schaltwerk:
Shimano Deore
Schalthebel:
Shimano Deore
Bremsen
Bremshebel:
Shimano Deore (160/160mm)**
Räder
Felgen:
Alex MD25***
Naben (V/H):
Shimano Deore
Bereifung:
Vittoria Barzo TNT | 29 x 2.1
Weitere Informationen
Produktsicherheitsverordnung (GPSR):
Sicherheitshinweise GPSR (EU)
Verantwortliche Person gemäss GPSR (EU)
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | ||||
| Reach | 405 | 426 | 442 | 458 |
| Stack | 605 | 615 | 624 | 633 |
| Bar Drop | ||||
| Bar Reach | ||||
| Bar Rise | 4 | 4 | 4 | 4 |
| Bar Sweep | 9 | 9 | 9 | 9 |
| Bar Width | 720 | 720 | 720 | 720 |
| Base Bar Drop Flat Cockpit | ||||
| Base Bar Drop V-Cockpit | ||||
| Base Bar Reach Flat Cockpit | ||||
| Base Bar Reach V-Cockpit | ||||
| BB Drop | 60 | 60 | 60 | 60 |
| BB Drop (SLACK) | ||||
| BB Drop (STEEP) | ||||
| BB Height (SLACK) | ||||
| BB Height (STEEP) | ||||
| Chainstay | ||||
| Crank Length | 170 | 175 | 175 | 175 |
| LT | BB Drop (SLACK) | ||||
| LT | BB Drop (STEEP) | ||||
| LT | BB Height (SLACK) | ||||
| LT | BB Height (STEEP) | ||||
| LT | Chainstay | ||||
| LT | Fork Length | ||||
| LT | Fork Rake | ||||
| LT | Frame Size | ||||
| LT | Front Center (SLACK) | ||||
| LT | Front Center (STEEP) | ||||
| LT | Head Tube | ||||
| LT | HT Angle (SLACK) | ||||
| LT | HT Angle (STEEP) | ||||
| LT | Reach (SLACK) | ||||
| LT | Reach (STEEP) | ||||
| LT | Rider Height | ||||
| LT | Seat Tube | ||||
| LT | ST Angle @750mm Saddle Height (SLACK) | ||||
| LT | ST Angle @750mm Saddle Height (STEEP) | ||||
| LT | ST Angle Actual (SLACK) | ||||
| LT | ST Angle Actual (STEEP) | ||||
| LT | ST Angle Effective (SLACK) | ||||
| LT | ST Angle Effective (STEEP) | ||||
| LT | Stack (SLACK) | ||||
| LT | Stack (STEEP) | ||||
| LT | Stand Over Height (80 in Front of BB) | ||||
| LT | Stand Over Height (Lowest Point) | ||||
| LT | Top Tube (SLACK) | ||||
| LT | Top Tube (STEEP) | ||||
| LT | Wheelbase (SLACK) | ||||
| LT | Wheelbase (STEEP) | ||||
| ST | BB Drop (SLACK) | ||||
| ST | BB Drop (STEEP) | ||||
| ST | BB Height (STACK) | ||||
| ST | BB Height (STEEP) | ||||
| ST | Chainstay | ||||
| ST | Fork Length | ||||
| ST | Fork Rake | ||||
| ST | Frame Size | ||||
| ST | Front Center (SLACK) | ||||
| ST | Front Center (STEEP) | ||||
| ST | Head Tube | ||||
| ST | HT Angle (SLACK) | ||||
| ST | HT Angle (STEEP) | ||||
| ST | Reach (SLACK) | ||||
| ST | Reach (STEEP) | ||||
| ST | Rider Height | ||||
| ST | Seat Tube | ||||
| ST | ST Angle @750mm Saddle Height (SLACK) | ||||
| ST | ST Angle @750mm Saddle Height (STEEP) | ||||
| ST | ST Angle Actual (SLACK) | ||||
| ST | ST Angle Actual (STEEP) | ||||
| ST | ST Angle Effective (SLACK) | ||||
| ST | ST Angle Effective (STEEP) | ||||
| ST | Stack (SLACK) | ||||
| ST | Stack (STEEP) | ||||
| ST | Stand Over Height (80 in Front of BB) | ||||
| ST | Stand Over Height (Lowest Point) | ||||
| ST | Top Tube (SLACK) | ||||
| ST | Top Tube (STEEP) | ||||
| ST | Wheelbase (SLACK) | ||||
| ST | Wheelbase (STEEP) | ||||
| Fork Length | 506 | 506 | 506 | 506 |
| Fork Rake | 51 | 51 | 51 | 51 |
| Frame Size | ||||
| Front Center | 656 | 685 | 704 | 724 |
| Front Center (SLACK) | ||||
| Front Center (STEEP) | ||||
| Head Tube | 90 | 100 | 110 | 120 |
| Head Tube Angle | 70 | 70 | 70 | 70 |
| HT Angle (SLACK) | ||||
| HT Angle (STEEP) | ||||
| Pad Reach Flat Cockpit | ||||
| Pad Reach V-Cockpit | ||||
| Pad Stack Flat Cockpit | ||||
| Pad Stack V-Cockpit | ||||
| Reach (SLACK) | ||||
| Reach (STEEP) | ||||
| Rear Center | 433 | 433 | 433 | 433 |
| Saddle Height Range | ||||
| Seat Angle | 73.5 | 73.5 | 73.5 | 73.5 |
| Seat Tube | 425 | 455 | 495 | 545 |
| Seatpost Drop | ||||
| Seatpost Length | 350 | 350 | 400 | 400 |
| Seatpost Offset | ||||
| ST Angle @750mm Saddle Height (SLACK) | ||||
| ST Angle @750mm Saddle Height (STEEP) | ||||
| ST Angle Actual (SLACK) | ||||
| ST Angle Actual (STEEP) | ||||
| ST Angle Effective (SLACK) | ||||
| ST Angle Effective (STEEP) | ||||
| Stack (SLACK) | ||||
| Stack (STEEP) | ||||
| Stand Over Height (80 in Front of BB) | ||||
| Stand Over Height (Lowest Point) | ||||
| Standover Height | ||||
| Stem Angle | 6 | 6 | 6 | 6 |
| Stem Length | 75 | 75 | 75 | 90 |
| Top Tube | 580 | 608 | 627 | 646 |
| Top Tube (SLACK) | ||||
| Top Tube (STEEP) | ||||
| Trail | 80 | 80 | 80 | 80 |
| Wheelbase | 1085 | 1113 | 1132 | 1152 |
| Wheelbase (SLACK) | ||||
| Wheelbase (STEEP) |
