Tecnologia
Panoramica tecnica
Telaio
Telaio:
 257 AMP Premium Aluminium | Smoothwelded | Integrated Battery | Internal Cable Routing | Powder Coat Finish | Post Mount Disc | 12 x 142mm Thru-Axle
Forcella:
 257 Premium Aluminium | Fender Mounts | Post Mount Disc | 12 x 100mm Thru-Axle
E-System
Unità di Trasmissione:
Bosch Performance Line Speed
Batteria:
Bosch PowerTube | 625 Wh | Certified by Intertek Testing Services NA, Inc.
Display:
Bosch Kiox
Controllo Dell'unità di Trasmissione:
Bosch Kiox
Caricabatterie:
Bosch Compact Charger
Cockpit
Attacco Manubrio:
ICS MTT x Redshift Suspension Stem | Integrated Cockpit System Technology
Piega:
BMC LSB 01
Seat
Reggisella:
BMC LSP 02
Sella:
Selle Royal Vivo
Gruppo
Guarnitura:
 Miranda Classic x Bosch | CF3D
Corona:
 46T
Pacco pignoni:
 SHIMANO CUES CS-LG700-11
Ingranaggi:
 11-50T
Catena:
SHIMANO CUES CN-LG500
Cambio:
 SHIMANO CUES RD-U8000
Comandi:
SHIMANO CUES SL-U8000
Rapporti:
 1 x 11
Freni
Leve Freno / Pinze:
 TEKTRO TRP HD
Dischi freno:
 TEKTRO
Diametro dischi:
 180 / 160mm
Ruote
Cerchi:
E-SRX30
Mozzi:
 CL-712 | ECT-142S
Pneumatici:
 Pirelli Angel GT | 37mm
Informazioni aggiuntive
Sezione max coperture:
42mm measured tire
Classificazione ASTM:
Level 2
Limite di peso massimale:
120kg
Regolamento sulla sicurezza generale dei prodotti (GPSR):
Avvertenze di sicurezza GPSR (UE)
Persona responsabile ai sensi del GPSR (UE)
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | <168 | 168-180 | 178-190 | >190 |
| Reach | 424 | 424 | 425 | 436 |
| Stack | 560 | 590 | 620 | 645 |
| Bar Width | 680 | 680 | 680 | 680 |
| BB Drop | 67 | 67 | 67 | 67 |
| Crank Length | 170 | 170 | 170 | 170 |
| Fork Length | 408 | 408 | 408 | 408 |
| Fork Rake | 45 | 45 | 45 | 45 |
| Front Center | 655 | 665 | 677 | 699 |
| Head Tube | 133 | 165 | 197 | 225 |
| Head Tube Angle | 70 | 70 | 70 | 70 |
| Rear Center | 440 | 440 | 440 | 440 |
| Seat Angle | 75 | 75 | 75 | 75 |
| Seat Tube | 480 | 510 | 540 | 570 |
| Seatpost Length | 350 | 350 | 350 | 350 |
| Seatpost Offset | 15 | 15 | 15 | 15 |
| Standover Height | 766 | 794 | 819 | 847 |
| Stem Angle | 0 | 0 | 0 | 0 |
| Stem Length | 70 | 70 | 80 | 90 |
| Top Tube | 574 | 582 | 591 | 609 |
| Trail | 75 | 75 | 75 | 75 |
| Wheelbase | 1085 | 1096 | 1108 | 1129 |
